Biomass Pelletizing Line

Production line for pellets or flat die pellet production
Production line for pellets or flat die pellet productionProduction line for pellets or flat die pellet productionProduction line for pellets or flat die pellet productionProduction line for pellets or flat die pellet production
Production line for pellets or flat die pellet production
Free
Linia granulare furaje si peletizare din resturi vegetale
Linie completa granule pana la  1000-1600 kg/ora
Materia prima: cereale,  lucerna, rapita, paie, furaje
Diametru peleti: 4-6-8 mm
Experienta peste 10 ani Garantie 12 luni
Pellet Production Line or Flat Die Pellet Production
Complete granulation line for feed pellets up to 1000-1600 kg/hour, pellet size: 4/6/8mm
MiniComplex Pellet Press - Rotary Flat Die Pellet Press 8mm - GFD-0.7
Raw material homogenization hopper - Volume: 3-5 cubic meters
Optional - Air Dryer for straw DAD-0.6-1.2, moisture up to 35% - 25kW
Baling straw baler square or round - CGS-1 or Hammer Mill H-119/7SN
Raw material: cereals, feed, straw, rapeseed, alfalfa, vegetable residues, etc.
The electrical consumption is 50% of the total installed power of the operating line.
12-month warranty from the start of the pellet production line
Services: Automation of biomass pellet production line, Spare parts, Training
Accessories: Flat die pellet mold 400 mm, Moisturizing system, Moisture display in flow, Steam generator, Hopper overload sensor, Pellet bagging
