Pellet Press - Granulator AMP-270
Technical specifications:
Pellet production capacity: up to 250 kg/hour depending on the raw material
Ring die size: 270 mm
Pellet diameter: 4 - 14 mm
Pellet length: 15 - 60 mm
Main motor: 1 x 22 kW
Dosing motor: 2 x 3 kW
Total installed power: 25 kW
Three-phase power supply - 400V, coil voltage 24V/230V within +/- 5%, frequency 50 Hz
Length: 5550 mm
Width: 3100 mm
Height: 4500 mm
Weight: 2500 kg
Raw material moisture content: 10 - 12 - 14% - moisture affects pellet quality and productivity
Raw material size: 3 - 5 mm
Pellet density at the outlet of the granulator: up to 1350 kg/m3
Bulk density in Big Bags: up to 700 kg/m3
Types of raw materials: wood shavings, cereal straw, alfalfa, feed, and other biomass waste
Each raw material has different tapering and sizes for the ring die.
Pellet Press AMP-270 consists of:
- Pellet Press AMP-270
- Raw material humidification system
- Automated lubrication system at an additional cost - recommended to use Total Ceran XM460 Grease
- Control panel and electrical system + soft starter
- Technology used since 2022
Pellet Press AMP-270 accessories
Raw material homogenization bunker V-3 cubic meters
Pellet conveyor belt
Cooler
Blower
Sieve, dedusting screener
Air compressor, Steam generator
Rollers, Ring dies for pellets 6-14mm - Germany GRAF, SALMATEC, Hungary, Italy
Consumables
Soft starter, Reactive power compensation panel
Aerodynamic dryer, Rotary dryer
Forestry waste shredding system, Straw bale shredding system
Automated and semi-automated bagging for pellets
